BT29: Sako TRG Rail Kit

$3995

The BT29 Sako TRG Rail Kit comes complete and ready to install onto your TRG stock. The kit allows for the installation of the BT12-QK Accu-Shot Precision Rail Monopod (BT12-QK is shown but not included). It is machined from 6061-T6 aluminum that is Mil-Spec Type III hard anodized. Available in black only.

Weight: 1.15 ounces

Installation of the BT29 REQUIRES the temporary removal of the butt pad assembly and drilling of a second hole. Although, this can be accomplished with common hand tools, B&T Industries L.L.C. strongly recommends a competent Gunsmith install the BT29 Sako TRG Rail Kit.

Proudly designed, engineered, machined and assembled in america

In stock

Categories: , Product ID: 712

Description

The BT12-QK is the only monopod that will work with the BT29 Sako TRG Rail Kit in order for it to lock in folded position.

NOTICE: B&T Industries L.L.C. strongly recommends a competent Gunsmith install the BT29 Sako TRG Rail Kit. We will not be responsible for any property damage resulting from the use or installation of their products.

INSTRUCTIONS:

  1. Remove the Butt Plate Base and Butt Plate Fastening Rail exposing the lower .50 ID frame tube.
  2. Remove any obstructions from this tube.
  3. Insert the Bar Nut into the frame tube.
  4. Using the long Guide Screw, locate the Bar Nut hole furthest away from the Guide Screw under the stock’s factory hole.
  5. Insert 10-32×3/4 screw through the hole in the widest portion of the Rail threading into the Bar Nut.
  6. Confirming the Rail is in-line with the stock, mark the location for the second hole.
  7. Remove the Rail and Bar Nut.
  8. Drill a 13/64 (.203) DIA. hole.
  9. Re-install the Bar Nut, Rail, Cushion and fasteners.

Additional information

Weight 1.15 oz
